1

2

3
Instead of remembering
 nothing about a lot of things,
 remember a little about a few things
4

5
Acute Alveolar Infiltrate
  • 1.
  • 2.
  • 3.
  • 4.
6
Acute Alveolar infiltrate
  • 1. Pulmonary edema
  • 2. Pneumonia
  • 3. Aspiration
  • 4. Hemorrhage
7

8

9
Anterior Mediastinal Masses
  • 1.
  • 2.
  • 3.
  • 4.
10
Anterior Mediastinal Masses
  • 1. Thymoma
  • 2. Teratoma
  • 3. Substernal thyroid
  • 4. Lymphoma
11

12

13
Opacified Hemithorax
  • 1.
  • 2.
  • 3.
  • 4.
14
Opacified Hemithorax
  • 1. Atelectasis
  • 2. Pleural effusion
  • 3. Pneumonia
  • 4. Post-pneumonectomy
15

16

17
Pneumomediastinum
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
18
Pneumomediastinum
  • 1. Ruptured esophagus
  • 2. Ruptured trachea/bronchus
  • 3. Iatrogenic
  • 4. Asthma
  • 5. Pneumoperitoneum
19

20

21
Chronic Alveolar Disease
  • 1.
  • 2.
  • 3.
  • 4.
22
Chronic Alveolar Disease
  • 1. Alveolar cell ca
  • 2. Alveolar sarcoid
  • 3. Lymphoma
  • 4. Alveolar proteinosis
23

24

25
Large Cavitary Lung Lesions
  • 1.
  • 2.
  • 3.
26
Large Cavitary Lung Lesions
  • 1. Abscess
  • 2. Carcinoma
  • 3. TB
27

28

29
Bibasilar Interstitial Disease
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
  • 6.
30
Bibasilar Interstitial Disease
  • 1. B
  • 2. A
  • 3. D
  • 4. A
  • 5. S
  • 6. S
31
Bibasilar Interstitial Disease
  • 1. Bronchiectasis
  • 2. Aspiration
  • 3. DIP
  • 4. Asbestosis
  • 5. Sickle Cell Disease
  • 6. Scleroderma
32

33

34
Upper Lobe Disease
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
35
Upper Lobe Disease
  • 1. TB (2° TB)
  • 2. Silicosis
  • 3. Eosinophilic granuloma
  • 4. Ankylosing spondylitis
  • 5. PCP rxd with Pentamadine prophylaxis
36

37

38
Micronodular Lung Disease
  • 1.
  • 2.
  • 3.
  • 4.
39
Micronodular Lung Disease
  • 1. Mets
  • 2. Sarcoid
  • 3. Pneumoconiosis
  • 4. Miliary TB
40

41

42
Chronic Interstitial Disease
Pulmonary Fibrosis
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
  • 6.
43
Chronic Interstitial Disease
Pulmonary Fibrosis
  • 1. Pneumoconiosis
  • 2. Interstitial Pneumonia
  • 3. Granulomatous disease
  • 4. Neoplastic disease
  • 5. Idiopathic fibrosis
  • 6. Collagen vascular disease
44

45

46
Small Cavitary Lung Lesions
  • 1.
  • 2.
  • 3.
  • 4.
47
Small Cavitary Lung Lesions
  • 1. Septic emboli
  • 2. Rheumatoid nodules
  • 3. Squamous or transitional cell mets
  • 4. Wegener’s Granulomatosis
48

49

50
Lymphangitic Spread to the Lungs
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
  • 6.
51
Lymphangitic Spread to the Lungs
  • 1. Lung ca
  • 2. Breast ca
  • 3. Stomach ca
  • 4. Pancreas ca
  • 5. Laryngeal ca
  • 6. Cervical ca
52

53

54
Multiple Lung Nodules
  • 1.
  • 2 .
  • 3.
  • 4.
  • 5.
55
Multiple Lung Nodules
  • 1. Mets
  • 2. Wegener’s granulomatosis
  • 3. Rheumatoid nodules
  • 4. AVMs
  • 5. Septic emboli
56

57

58
Pulmonary Interstitial Edema
  • 1.
  • 2.
  • 3.
59
Pulmonary Interstitial Edema
  • 1. CHF
  • 2. Lymphangitic spread
  • 3. Allergic reaction
60

61

62
Shifting Infiltrates
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
63
Shifting Infiltrates
  • 1. Loeffler’s syndrome
  • 2. ABPA
  • 3. Asthma
  • 4. Polyarteritis
  • 5. Viral pneumonia
64

65

66
Unilateral Hyperlucent Lung
  • 1.
  • 2.
  • 3.
  • 4.
67
Unilateral Hyperlucent Lung
  • 1. Swyer-James syndrome
  • 2. Pulmonary embolism
  • 3. Pneumothorax
  • 4. Obstructive emphysema
68

69

70
Rapidly Clearing Alveolar Infiltrate
  • 1.
  • 2.
  • 3.
  • 4.
71
Rapidly Clearing Alveolar Infiltrate
  • 1. Hemorrhage
  • 2. Pulmonary edema
  • 3. Aspiration
  • 4. Pneumococcal pneumonia
72

73

74
Cavitating Pneumonia
  • 1.
  • 2.
  • 3.
  • 4.
75
Cavitating Pneumonia
  • 1. Staph
  • 2. Strep
  • 3. TB
  • 4. Gram negative (Klebsiella)
76

77

78
Middle Mediastinal Masses
  • 1.
  • 2.
  • 3.
  • 4.
79
Middle Mediastinal Masses
  • 1. Lymphadenopathy
  • 2. Aneurysms
  • 3. Esophageal duplication
  • 4. Bronchogenic cysts
80

81

82
Masses with Air Bronchograms
  • 1.
  • 2.
  • 3.
83
Masses with Air Bronchograms
  • 1. Lymphoma
  • 2. Alveolar cell ca
  • 3. Pseudolymphoma (Maltoma)
84

85

86
Hilar Adenopathy
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
87
Hilar Adenopathy
  • 1. Sarcoid
  • 2. TB
  • 3. Lymphoma
  • 4. Bronchogenic ca
  • 5. Mets
88

89

90
Cavities Containing Masses
  • 1.
  • 2.
  • 3.
  • 4.
91
Cavities Containing Masses
  • 1. Aspergillosis
  • 2. Cavitating bronchogenic ca
  • Tuberculosis
  • Hydatid cyst



92

93

94
Infiltrates with Effusion
  • 1.
  • 2.
  • 3.
  • 4.
95
Infiltrates with Effusion
  • 1. Staph pneumonia
  • 2. Strep pneumonia
  • 3. TB
  • 4. Pulmonary infarct
96

97

98
“Mass”+ ipsilateral adenopathy
  • 1.
  • 2.
  • 3.
99
“Mass”+ ipsilateral adenopathy
  • 1. Bronchogenic ca
  • 2. Lymphoma
  • 3. TB
100

101

102
Solitary Pulmonary Nodule
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
  • 6.
  • 7.
  • 8.
103
Solitary Pulmonary Nodule
  • 1. Bronchogenic ca
  • 2. Hamartoma
  • 3. Histoplasmoma
  • 4. TB granuloma
  • 5. Bronchial adenoma
  • 6. Solitary met
  • 7. Round pneumonia
  • 8. Rounded atelectasis
104

105

106
Pleural Effusion
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
  • 6.
  • 7.
  • 8.
  • 9.
107
Pleural Effusion
  • 1. CHF
  • 2. Mets
  • 3. Pancreatitis
  • 4. Pulmonary embolism
  • 5. Trauma
  • 6. Empyema
  • 7. Collagen vascular
  • 8. Ovarian tumor (Meig’s Syndrome)
  • 9. Chylothorax
108

109

110
Left-sided Pleural Effusion
  • 1.
  • 2.
  • 3.
  • 4.
111
Left-sided Pleural Effusion
  • 1. Boerhaave’s Syndrome
  • 2. Dissecting aortic aneurysm
  • 3. Pancreatitis
  • 4. Distal thoracic duct rupture
112

113

114
Multiple Small Calcifications
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
115
Multiple Small Calcifications
  • 1. Histoplasmosis
  • 2. Silicosis
  • 3. Chicken pox pneumonia
  • 4. Pulmonary ossification 2° MS
  • 5. Alveolar microlithiasis
116

117

118
Posterior Mediastinal Masses
  • 1.
  • 2.
  • 3.
119
Posterior Mediastinal Masses
  • 1. Neurogenic tumors
  • 2. Lymphadenopathy
  • 3. Extramedullary hematopoesis
120

121

122
Mediastinal Adenopathy
  • 1.
  • 2.
  • 3.
  • 4.
  • 5.
123
Mediastinal Adenopathy
  • 1. Bronchogenic ca
  • 2. Lymphoma
  • 3. TB
  • 4. Mets
  • 5. Sarcoid
124

125

126
Lung Disease & Rib Destruction
  • 1.
  • 2.
  • 3.
  • 4.
127
Lung Disease & Rib Destruction
  • 1. Bronchogenic ca, i.e Pancoast tumor
  • 2. Actinomycosis
  • 3. Blastomycosis
  • 4. Multiple myeloma
128

129

130
Pleural Calcification
  • 1.
  • 2.
  • 3.
131
Pleural Calcification
  • 1. Old TB empyema
  • 2. Asbestos exposure
  • 3. Hemothorax
132

133

134
“Masses” in Cardiophrenic Angle
  • 1.
  • 2.
  • 3.
135
“Masses” in Cardiophrenic Angle
  • 1. Sequestration
  • 2. Diaphragmatic hernia
  • 3. Pericardial cyst
136

137

138
Unilateral Pulmonary Edema
  • 1.
  • 2.
  • 3.
  • 4.
139
Unilateral Pulmonary Edema
  • 1. Aspiration
  • 2. Disease in other lung, e.g. COPD
  • 3. Postural
  • 4. Rapid expansion of PTX
140

141

142
Reverse “Pulmonary Edema”
  • 1.
  • 2.
  • 3.
143
Reverse “Pulmonary Edema”
  • 1. Eosinophilic lung disease, e.g. Loeffler’s
  • 2. Sarcoid
  • 3. Pulmonary contusions
144
