General Considerations

• Loculation of cerebrospinal fluid (CSF) at the distal end of the a ventriculoperitoneal shunt tube
• May occur secondary to adhesions
• Leads to an enlarging abdominal and/or pelvic mass at catheter tip
• CSF from tip is no longer absorbed by peritoneum

Clinical Findings

• Local signs of  an abdominal mass
• Increased intracranial pressure signs

Imaging Findings

• Diagnosis is most often made by ultrasound
  • Sonolucent mass
• Up to 2 liters of fluid

Treatment

• Can resolve spontaneously
• Shunt revision and repositioning
• Aspiration of cyst’s contents

Complications

• Infection of pseudocyst can reach >76% in children under 4 years
• Overall infection rate is 30%





CSFoma. CT scan of lower abdomen at left shows a large fluid-filled cystic mass (black arrow) at the termination of the coiled ventriculoperitoneal shunt tube (red arrows) seen traversing the chest in the chest radiograph at right (white arrows).
For more information, click on the link if you see this icon

For this same photo without the annotations, click here or here
